Amphenol 26系列連接器
發布時間：2024-07-16 09:19:11 瀏覽：5446
Amphenol
26系列連接器是一系列專為工業控制儀器、測試設備和運輸領域設計的高性能機架和面板連接器。這些連接器以其堅固耐用和重型互連能力而著稱，適用于在狹小空間內進行可靠的電氣連接。
應用領域：
- 工業控制儀器
- 測試設備
- 運輸領域
技術規格：
工作電壓：750V AC
工作電流：5A
工作溫度范圍：-55℃至+125℃
材料：使用高質量的絕緣體和接觸材料，如玻璃填充二芐基鄰苯二甲酸酯(Glass-filled DAP)、磷青銅和黃銅等。
接觸電阻：最大11毫歐
絕緣電阻：最小5000兆歐
耐壓：1200V RMS
連接器配合力和脫離力：根據針數不同，配合力和脫離力有所不同，確保連接的穩定性和可靠性。
顏色：藍色
型號：
| 8 Pin插頭 |
| CONNECTOR P/N | NO.OF | TERMINATION | CONTACT | LEVEL |
| CONT. | TYPE | FINISH |
| 26-182 | 8 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-08P-004 | 8 | SOLDER | GOLD PLATE OVER | 3 |
| NICKEL |
| 26-08P-99 | 8 | SOLDER | SILVERPL.&TIN | 一 |
| LEAD SOLDER DIP |
| ON TERMINATION |
| 8 Pin插座 |
| 26-183 | 8 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-08S-004 | 8 | SOLDER | GOLD PLATE OVER | 3 |
| NICKEL |
| 26-08S-99 | 8 | SOLDER | SILVER PL.&TIN | 一 |
| LEAD sOLDER DIP |
| ON TERMINATION |
| 16 Pin插頭 |
| 26-159-16 | 16 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-16P-004 | 16 | SOLDER | ---DO -- | 3 |
| 26-16P-99 | 16 | SOLDER | MATING:SILVER | 一 |
| TERMINATION: |
| TIN LEAD SOLDER |
| DIPOVER SILVER |
| 16 Pin插座 |
| 26-190-16 | 16 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-16S -004 | 16 | SOLDER | ---DO --- | 3 |
| 26-16S-99 | 16 | SOLDER | MATING:SILVER |
|
| TERMINATION: |
| TIN LEAD SOLDER |
| DIPOVER SILVER |
| 24 Pin插頭 |
| 26-159-24P | 24 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-24P-004 | 24 | SOLDER | GOLD PLATE OVER | 3 |
| NICKEL |
| 26-24P-99 | 24 | SOLDER | SILVER PL.&TIN | 一 |
| LEAD SOLDER DIP |
| ON TERMINATION |
| 24 Pin插座 |
| 26-190-24S | 24 | SOLDER | GOLD PLATE OVER | 1 |
| NICKEL |
| 26-24S-004 | 24 | SOLDER | GOLD PLATE OVER | 3 |
| NICKEL |
| 26-24S-99 | 24 | SOLDER | SILVER PL.&TIN |
|
| LEAD SOLDER DIP |
| ON TERMINATION |
