LINEAR電源isoPower
發布時間：2022-06-21 16:37:40 瀏覽：1164
LINEAR電源的isoPower?技術應用選用特有的iCoupler?芯片級變壓器，能在單封裝中完成隔離式dc-dc轉換和數據隔離的整合。因此設計人員能夠克服光耦合器的成本費用、規格尺寸、功能損耗、性能和可靠性的限制，在設計中完成隔離。現階段已有10億個以上的隔離通道投放使用。LINEAR電源isoPower磁性隔離產品安全可靠且便于使用，是光耦合器的理想化替代產品。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.imhgnv.cn/brand/19.html
產品型號 | # of Channels | Prop Delay (max) | Iout Isolated Supply (max) | Iso Vout (min) | Insulation Rating | CMTI (min) | Vs+ (min) | Vs+ (max) |
|
| s | A | V | V rms | V/us | V | V |
ADP1034 | 3 | 15n | 150m | 6 | 2.5k | 25k | 1.8 | 5.5 |
ADUM6423A | 4 | 17n | 100m | 3.135 | 5k | 75k | 1.7 | 5.5 |
ADUM6424A | 4 | 17n | 100m | 3.135 | 5k | 75k | 1.7 | 5.5 |
ADUM6422A | 4 | 17n | 100m | 3.135 | 5k | 75k | 1.7 | 5.5 |
ADP1032 | 2 | 15n | 150m | 6 | 2.5k | 25k | 1.8 | 5.5 |
ADUM6420A | 4 | 17n | 100m | 3.135 | 5k | 75k | 1.7 | 5.5 |
ADUM6421A | 4 | 17n | 100m | 3.135 | 5k | 75k | 1.7 | 5.5 |
ADP1031 | 3 | 15n | 100m | 6 | 2.5k | 25k | 1.8 | 5.5 |
ADUM5020 | 0 |
| 100m | 3 | 3k |
| 3 | 5.5 |
ADUM5028 | 0 |
| 60m | 3 | 3k |
| 3 | 5.5 |
ADUM6020 | 0 |
| 100m | 3 | 5k |
| 3 | 5.5 |
ADUM6028 | 0 |
| 60m | 3 | 5k |
| 3 | 5.5 |
LTM2886 | 6 |
| 100m | -5 | 2.5k | 30k | 1.62 | 5.5 |
LTM2889-3 | 1 | 275n | 125m | 3 | 2.5k | 30k | 1.62 | 5.5 |
LTM2889-5 | 1 | 275n | 200m | 3 | 2.5k | 30k | 1.62 | 5.5 |
ADUM5410 | 4 | 14n | 30m | 3 | 2.5k | 75k | 3 | 5.5 |
ADUM5411 | 4 | 14n | 30m | 3 | 2.5k | 75k | 3 | 5.5 |
ADUM5412 | 4 | 14n | 30m | 3 | 2.5k | 75k | 3 | 5.5 |
ADUM6410 | 4 | 14n | 30m | 3 | 3.75k | 75k | 3 | 5.5 |
ADUM6411 | 4 | 14n | 30m | 3 | 3.75k | 75k | 3 | 5.5 |
ADUM6412 | 4 | 14n | 30m | 3 | 3.75k | 75k | 3 | 5.5 |
LTM2885 | 1 |
| 200m | 4.75 | 6.5k | 50k | 1.62 | 5.5 |
LTM2887 | 6 |
| 100m | 5 | 2.5k | 30k | 1.62 | 5.5 |
LTM2884 | 1 | 300n | 500m | 4.75 | 2.5k | 30k | 4.4 | 16.5 |
ADM3260 | 2 | 95n | 30m | 4.5 | 2.5k | 25k | 3 | 5.5 |
ADUM4470 | 4 | 60n | 400m | 3.3 | 5k | 25k | 3 | 5.5 |
ADUM4471 | 4 | 60n | 400m | 3.3 | 5k | 25k | 3 | 5.5 |
ADUM4472 | 4 | 60n | 400m | 3.3 | 5k | 25k | 3 | 5.5 |
ADUM4473 | 4 | 60n | 400m | 3.3 | 5k | 25k | 3 | 5.5 |
ADUM4474 | 4 | 60n | 400m | 3.3 | 5k | 25k | 3 | 5.5 |
ADUM5210 | 2 | 29n | 30m | 3.085 | 2.5k | 25k | 3 | 5.5 |
ADUM5211 | 2 | 29n | 30m | 3.085 | 2.5k | 25k | 3 | 5.5 |
ADUM5212 | 2 | 29n | 30m | 3.085 | 2.5k | 25k | 3 | 5.5 |
ADUM6210 | 2 | 29n | 30m | 3.085 | 3.75k | 25k | 3 | 5.5 |
ADUM6211 | 2 | 29n | 30m | 3.085 | 3.75k | 25k | 3 | 5.5 |
ADUM6212 | 2 | 29n | 30m | 3.085 | 3.75k | 25k | 3 | 5.5 |
ADUM4070 | 0 |
| 500m | 3.5 | 5k | 25k | 3 | 5.5 |
ADUM5010 | 0 |
| 30m | 3.3 | 2.5k | 25k | 3.3 | 5.5 |
ADUM6010 | 0 |
| 30m | 3.3 | 3.75k | 25k | 3 | 5.5 |
LTM2883 | 6 |
| 30m | -12.5 | 2.5k | 30k | 1.62 | 5.5 |
ADUM3070 | 0 |
| 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM3470 | 4 | 60n | 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM3471 | 4 | 60n | 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM3472 | 4 | 60n | 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM3473 | 4 | 60n | 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM3474 | 4 | 60n | 400m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM6000 | 0 |
| 100m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6200 | 2 | 45n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6201 | 2 | 45n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6202 | 2 | 45n | 80m | 3 | 5k | 25k | 3 | 5.5 |
LTM2881-3 | 1 |
| 125m | 4.75 | 2.5k | 30k | 1.62 | 5.5 |
LTM2881-5 | 1 |
| 200m | 4.75 | 2.5k | 30k | 1.62 | 5.5 |
ADUM6400 | 4 | 60n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6401 | 4 | 60n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6402 | 4 | 60n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6403 | 4 | 60n | 80m | 3 | 5k | 25k | 3 | 5.5 |
ADUM6404 | 4 | 60n | 80m | 3 | 5k | 25k | 3 | 5.5 |
LTM2882-3 | 2 | 500n | 125m | 4.8 | 2.5k | 30k | 3 | 3.6 |
LTM2882-5 | 2 | 500n | 200m | 4.8 | 2.5k | 30k | 4.5 | 5.5 |
ADUM5000 | 0 |
| 100m | 3 | 2.5k |
| 3 | 5.5 |
ADUM5200 | 2 | 70n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5201 | 2 | 70n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5202 | 2 | 70n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5400 | 4 | 60n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5401 | 4 | 60n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5402 | 4 | 60n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5403 | 4 | 60n | 100m | 3 | 2.5k | 25k | 3.5 | 5.5 |
ADUM5404 | 4 | 60n | 100m | 3 | 2.5k | 25k | 3 | 5.5 |
ADUM5240 | 2 | 70n | 10m | 4.5 | 2.5k | 25k | 2.7 | 5.5 |
ADUM5241 | 2 | 70n | 10m | 4.5 | 2.5k | 25k | 2.7 | 5.5 |
ADUM5242 | 2 | 70n | 10m | 4.5 | 2.5k | 25k | 2.7 | 5.5 |
