LINEAR電源穩壓升壓電荷泵
發布時間：2022-02-28 17:00:58 瀏覽：889
LINEAR穩壓升壓電荷泵系列主要用于將輸入電壓增加或增加到更高水平。與傳統的感性電源開關相比較，由于不需要電感，LINEAR電源穩壓升壓電荷泵提供了一個小的解決方案規格尺寸和簡單的設計。其主要特點包括低靜態電流、多工作模式、高達500個自動模式切換性能mA的Iout、低噪聲恒頻作業，突發工作模式(Burst Mode)、過溫、故障和過流保護。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://www.imhgnv.cn/brand/19.html
產品型號 | Number of Outputs | Vin (min) | Vin (max) | Output Current (typ) | Output Voltage | Isupply (typ) |
|
| V | V | A |
| A |
LTC3290 | 1 | 4.5 | 55 | 50m | 1V + Vin + Vaux | 15μ |
LTC3265 | 2 | 4.5 | 32 | 50m | Adj, -Adj | 85μ |
LTC3221 | 1 | 1.8 | 5.5 | 60m | 3.3V, 5V, Adj | 8μ |
LTC3203 | 1 | 2.7 | 5.5 | 500m | 5V | 120μ |
LTC3240 | 1 | 1.8 | 5.5 | 150m | 2.5V, 3.3V | 65μ |
LTC3200 | 1 | 2.7 | 4.5 | 100m | 5V, Adj | 3.5m |
LTC3201 | 1 | 2.7 | 4.5 | 100m | Adj | 4m |
LTC3202 | 1 | 2.7 | 4.5 | 125m | Adj | 2.5m |
LTC1751 | 1 | 2 | 5.5 | 100m | Adj | 20μ |
LTC1751-3.3 | 1 | 2 | 5.5 | 100m | 3.3V | 20μ |
LTC1751-5 | 1 | 2 | 5.5 | 100m | 5V | 20μ |
LTC1928-5 | 1 | 2.7 | 4.4 | 30m | 5V | 190μ |
LTC1555L | 1 | 2.6 | 6.6 | 20m | 3V, 5V | 40μ |
LTC1555L-1.8 | 1 | 2.6 | 6.6 | 20m | 1.8V, 3V, 5V | 32μ |
LTC1754-3.3 | 1 | 2 | 4 | 40m | 3.3V | 13μ |
LTC1754-5 | 1 | 2 | 4 | 40m | 5V | 13μ |
LTC1755 | 1 | 2.7 | 6 | 60m | 3V, 5V | 60μ |
LTC1986 | 1 | 2.6 | 4.4 | 10m | 5V, Vin | 14μ |
LTC1502-3.3 | 1 | 900m | 1.8 | 10m | 3.3 | 40μ |
LTC1682 | 1 | 1.8 | 4.4 | 50m | 3.3V, 5V, Adj | 150μ |
LTC1756 | 1 | 2.7 | 6 | 60m | 3V, 5V | 60μ |
LTC1517-3.3 | 1 | 2.2 | 4.4 | 15m | 3.3V | 6μ |
LTC1514 | 1 | 2.7 | 10 | 50m | 3.3, 5V | 60μ |
LTC1515 | 1 | 2.7 | 10 | 50m | 3.3V, 5V | 60μ |
LTC1517-5 | 1 | 2.7 | 5 | 20m | 5V | 6μ |
LTC1522 | 1 | 2.7 | 5 | 20m | 5V | 6μ |
LTC1555 | 1 | 2.7 | 10 | 20m | 5V | 60μ |
LTC1556 | 1 | 2.7 | 10 | 20m | 5V | 60μ |
LTC1263 | 1 | 5 | 5 | 60m | 12V | 300μ |
LTC1516 | 1 | 2 | 5 | 50m | 5V | 12μ |
LTC1262 | 1 | 5 | 5 | 30m | 12V | 500μ |
LT1054 | 1 | 3.5 | 15 | 100m | Adj | 2.5m |
LT1054L | 1 | 3.5 | 7 | 125m | Adj | 2.5m |
