ADI RF功率檢波器
發布時間：2021-03-09 16:57:52 瀏覽：7106
ADI提供了一系列高性能的射頻探測器，可以精確地檢測和測量無線系統中的射頻和中頻信號。ADI對數放大器可以測量動態范圍高達100db的信號，工作頻率范圍從直流到微波，精度高達±2db，非常適合RSSI和傳輸功率電平的檢測。TruPwr? rms均方根檢測器解決了擴頻碼分多址（CDMA/W-CDMA）和高階QAM調制系統中復雜波形的測量問題，提供了一個精確調節的直流電壓，其值等于輸入波形的均方根等效有效值。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
詳情了解ADI芯片請點擊：http://www.imhgnv.cn/brand/25.html
或聯系我們的銷售工程師： 0755- 83642657 QQ： 2295048674
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Input Dynamic Range (typ) | Temp Drift (typ) | Specified at Freq | Pin Test Level | Is (typ) | Vs+ (min) | Vs+ (max) |
| Hz | Hz | dB | dB | Hz | dBm | A | V | V |
LTC5597 | 100M | 70G | 35 | 1 | 42G |
| 33.5m | 2.7 | 3.6 |
ADL6012 | 2G | 67G | 40 | 1 | 18G |
| 28.6m | 3.15 | 5.25 |
ADL5920 | 9k | 7G | 50 | 0.5 | 1G | -10 | 160m | 4.9 | 5.1 |
ADL6010S | 500M | 43.5G | 45 | 0.3 |
|
| 3m | 4.78 | 5.25 |
ADL5910 | 0 | 6G | 45 | 0.5 | 900M | 10 | 3.5m | 3.15 | 3.45 |
ADL5904 | 0 | 6G | 45 | 0.5 | 900M | 10 | 3.5m | 3.15 | 3.45 |
LTC5596 | 100M | 40G | 35 | 1.25 | 40G | -25 | 30m | 2.7 | 3.5 |
ADL6010 | 500M | 43.5G | 45 | 0.3 | 10G | -10 | 3m | 4.78 | 5.25 |
ADL5506 | 30M | 4.5G | 45 | 1 | 900M | -10 | 3.75m | 2.5 | 5.5 |
ADL5903 | 200M | 6G | 35 | 0.2 | 900M | -10 | 2.5m | 3 | 5.25 |
HMC1120 | 0 | 3.9G | 72 | 0.5 | 1900M |
| 70m | 3.15 | 3.45 |
HMC1094 | 1G | 23G | 50 | 0.5 | 10M | -10 | 85m | 3.15 | 3.45 |
HMC7447 | 71G | 86G | 24 | 0.5 | 81G | 18 |
| 3 | 5 |
ADL5906 | 10M | 10G | 67 | 1 | 900M | -10 | 70m | 4.75 | 5.25 |
ADL5501S | 50M | 6G | 30 |
|
|
|
| 2.7 | 5.5 |
ADL5513S | 1M | 4G | 80 |
| 900M | -10 |
| 2.7 | 5.5 |
AD8306S | 5M | 400M | 100 |
| 10M | 0 |
| 2.7 | 6.5 |
ADL5304 |
|
| 200 |
|
|
| 20.8m | 4.5 | 5.5 |
ADL5511 | 0 | 6G | 47 | 0.1 | 900M | 10 | 21.5m | 4.75 | 5.25 |
HMC1013 | 500M | 18.5G | 67 | 0.5 | 10G | 0 | 183m |
| 3.3 |
HMC1030 | 0 | 3.9G | 69 | 0.5 | 900M | -10 | 143m | 5 | 5 |
HMC662 | 8G | 30G | 54 | 0.5 | 10M | -10 | 88m | 3.15 | 3.45 |
LTC5583 | 40M | 6G | 60 | 0.5 | 2.14G | -45 | 80.5m | 3.1 | 3.5 |
LTC5587 | 10M | 6G | 40 | 1 | 2.14G |
| 3m | 2.7 | 3.6 |
ADL5505 | 450M | 6G | 36 | 0.1 | 900M | 10 | 1.8m | 2.5 | 3.3 |
ADL5902 | 50M | 9G | 65 | 0.5 | 900M | -10 | 73m | 4.5 | 5.5 |
LTC5582 | 40M | 10G | 57 | 0.5 | 2.14G | -45 | 41.6m | 3.1 | 3.5 |
HMC1010 | 0 | 3.9G | 62 | 0.5 | 900M | 0 | 48m | 4.5 | 5.5 |
HMC1020 | 0 | 3.9G | 72 | 0.75 | 900M | -10 | 55m | 4.5 | 5.5 |
HMC1021 | 0 | 3.9G | 70 | 0.5 | 900M | -10 | 75m | 4.5 | 5.5 |
HMC813-Die | 1G | 26G | 55 | 0.5 |
|
| 150m |
|
|
HMC813LC4B | 1G | 20G | 55 | 0.5 | 10G | -10 | 150m |
|
|
HMC909 | 0 | 5.8G | 40 | 0.5 | 900M | -15 | 42m | 4.5 | 5.5 |
HMC913-Die | 0.6G | 20G | 59 | 1.5 | 18G | -30 | 80m |
|
|
HMC913LC4B | 0.6G | 20G | 59 |
| 10G | -10 | 80m |
|
|
HMC948 | 1G | 23G | 54 | 0.5 | 10M | -10 | 91m | 3.15 | 3.45 |
LTC5564 | 600M | 15G | 40 | 2 | 5.8G | 5 | 44m | 3.1 | 5.5 |
ADL5504 | 450M | 6G | 35 | 0.1 | 900M | 10 | 1.8m | 2.5 | 3.3 |
AD8363 | 50 | 6G | 60 | 0.5 | 900M | -10 | 60m | 4.5 | 5.5 |
HMC713LP3E | 50M | 8G | 54 | 0.5 | 2.7G |
| 17m | 2.7 | 5.5 |
HMC713MS8 | 45M | 2.7G | 54 | -0.5 | 2.7G |
| 17m | 2.7 | 5.5 |
ADL5502 | 450M | 6G | 35 | 0.1 | 900M | 10 | 3m | 2.5 | 3.3 |
ADL5513 | 1M | 4G | 80 | 0.5 | 900M | -10 | 31m | 2.7 | 5.5 |
LT5581 | 10M | 6G | 40 | 1 | 2.14G |
| 1.4m | 2.7 | 6 |
LT5538 | 40M | 3.8G | 75 | 0.5 | 2.14G | -35 | 29m | 3 | 5.25 |
ADL5519 | 1M | 10G | 62 | 0.5 | 0.9M | -10 | 60m | 3.3 | 5.5 |
HMC611LP4 | 1M | 10G | 60 |
| 7G | -10 | 106m | 4.5 | 5.5 |
HMC613 | 100M | 20G | 59 | 0.5 | 10G | -10 | 83m | 3.15 | 3.45 |
LT5570 | 40M | 2.7G | 51 | 0.5 | 2.14G | -30 | 26.5m | 4.75 | 6 |
ADL5501 | 50M | 6G | 30 | 0.1 | 900M | 5 | 1.1m | 2.7 | 5.5 |
HMC600 | 50M | 4G | 75 | 0.5 | 900M | -15 | 29m | 2.7 | 5.5 |
HMC601 | 10M | 4G | 75 | 0.5 | 900M | -15 | 30m | 4.5 | 5.5 |
HMC602 | 1M | 8G | 70 | 1 | 0.9M | -10 | 113m | 4.5 | 5.5 |
AD8317 | 1M | 10G | 55 | 0.5 | 0.9M | -10 | 22m | 3 | 5.5 |
AD8319 | 1M | 10G | 45 | 0.5 | 0.9M | -10 | 22m | 3 | 5.5 |
AD8311 | 100M | 2.5G | 50 | 0.5 |
|
| 7.6m | 2.7 | 5.5 |
ADL5500 | 100M | 6G | 30 | 0.25 | 900M | 2.5 | 1m | 2.7 | 5.5 |
LT5537 | 0 | 1G | 83 | 0.63 | 200M | -20 | 13.5m | 2.7 | 5.25 |
AD8312 | 50M | 3.5G | 45 | 0.5 | 900M | -10 | 4.2m | 2.7 | 5.5 |
AD8364 | 0 | 2.7G | 60 | 0.5 | 900M | -10 | 70m | 4.5 | 5.5 |
LTC5536 | 600M | 7G | 38 | 1 | 7G | 4 | 2.1m | 2.7 | 5.5 |
AD8318 | 1M | 8G | 70 | 0.5 | 0.9M | -10 | 68m | 4.5 | 5.5 |
LTC5535 | 600M | 7G | 42 | 1 | 5G |
| 2m | 2.7 | 5.5 |
LT5534 | 50M | 3G | 60 | 0.75 | 1.9G | -30 | 7m | 2.7 | 5.25 |
LTC5530 | 300M | 7G | 42 | 1.2 | 5G |
| 500μ | 2.7 | 6 |
LTC5533 | 300M | 11G | 40 | 1 | 5G |
| 900μ | 2.7 | 6 |
ADL5310 |
|
| 120 |
|
|
| 9.5m | 3 | 12 |
ADL5306 |
|
| 60 |
|
|
| 5.4m | 3 | 5.5 |
LTC5532EDC | 300M | 12G | 42 | 1.2 | 5G |
| 500μ | 2.7 | 6 |
LTC5532ES6 | 300M | 7G | 42 | 1.2 | 5G |
| 500μ | 2.7 | 6 |
LTC5509 | 300M | 3G | 36 | 0.5 | 1.85G |
| 580μ | 2.7 | 6 |
LTC5531 | 300M | 7G | 42 | 1.2 | 5G |
| 500μ | 2.7 | 6 |
AD8305 |
|
| 100 |
|
|
| 5.4m | 3 | 12 |
AD8362 | 50 | 3.8G | 65 | 1 | 900M | 0 | 20m | 4.5 | 5.5 |
LTC4401-2 | 300M | 2G |
|
|
|
| 1m | 2.7 | 6 |
LTC5507 | 100k | 1G | 48 | 1 | 1G | -10 | 550μ | 2.7 | 6 |
AD8304 |
|
| 160 |
|
|
| 4.5m | 3 | 5.5 |
LTC5508 | 300M | 7G | 44 | 2 | 5G | -12 | 550μ | 2.7 | 6 |
AD8302 | 0 | 2.7G | 60 | 1 | 900M | -30 | 19m | 2.7 | 5.5 |
LTC5505-1 | 300M | 3G | 46 | 1 | 1.85G |
| 500μ | 2.7 | 6 |
LTC5505-2 | 300M | 3.5G | 44 | 1 | 1.85G |
| 500μ | 2.7 | 6 |
AD8315 | 100M | 2.5G | 50 | 1 |
|
| 8.5 | 2.7 | 5.5 |
AD8310 | 0 | 440M | 95 | 1 | 100M | 0 | 8m | 2.7 | 5.5 |
AD8314 | 100M | 2.7G | 45 | 1 | 900M | -10 | 4.5m | 2.7 | 5.5 |
AD8361 | 0 | 2500M | 30 | 0.25 | 900M | 5 | 1.1m | 2.7 | 5.5 |
AD8306 | 5M | 400M | 100 | 1 | 10M | 0 | 16m | 2.7 | 6.5 |
AD8309 | 5M | 500M | 100 | 1 | 100M | 0 | 16m | 2.7 | 6.5 |
AD8313 | 100M | 2.5G | 70 | 1.25 | 900M | -10 | 13.7m | 2.7 | 5.5 |
AD8307 | 0 | 500M | 92 | 1 | 100M | 0 | 8m | 2.7 | 5.5 |
AD641 | 0 | 250M | 44 | 1 |
|
| 35m | 4.5 | 7.5 |
AD640 | 0 | 120M | 50 | 1 |
|
| 35m | 4.5 | 7.5 |
