ADI驅動放大器
發布時間：2021-02-22 17:12:34 瀏覽：1512
ADI驅動放大器提供從400兆赫（中頻）到射頻微波和W波段（86千兆赫）的頻率范圍廣泛的中功率通用放大器。ADI驅動放大器的輸出功率為15 DBM至約1 W，涵蓋各種頻率、帶寬和增益水平。大多數設計內部匹配50Ω，并提供包括模具和封裝組件的設計。所有ADI驅動放大器在整個頻率、溫度和電源電壓范圍內提供額定性能。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
詳情了解ADI芯片請點擊：http://www.imhgnv.cn/brand/25.html
或聯系我們的銷售工程師： 0755- 83642657 QQ： 2295048674
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | OP1dB (typ) | OIP3 (typ) | Vs (typ) | Is (typ) |
| Hz | Hz | dB | dBm | dBm | V | A |
ADL8150-Die | 6G | 14G | 13 | 19 | 31.5 | 5 | 76m |
ADL8150ACPZN | 6G | 14G | 12 | 18 | 30 | 5 | 74m |
HMC1022A-Die | 0 | 48G | 11.5 | 21 | 29 | 10 | 150m |
HMC5805A | 0 | 40G | 11.5 | 24.5 | 29 | 10 | 175m |
HMC1131 | 24G | 35G | 20 | 24 | 35 | 5 | 225m |
HMC7543 | 71G | 76G | 21.5 | 25 | 30 | 4 | 450m |
HMC8142 | 81G | 86G | 21 | 25 | 29 | 4 | 450m |
HMC1082-Die | 5.5G | 18G | 24 | 25.5 | 36 | 5 | 220m |
HMC1082LP4E | 5.5G | 18G | 22 | 24 | 35 | 5 | 220m |
ADL5324 | 400M | 4G | 14 | 27.2 | 45.5 | 3.3 | 60m |
ADL5605 | 700M | 1G | 23 | 31.4 | 43.4 | 5 | 307m |
ADL5606 | 1.8G | 2.7G | 24.3 | 30.8 | 45.5 | 5 | 362m |
ADL5604 | 700M | 2.7G | 12.2 | 29.1 | 42.2 | 5 | 318m |
HMC789 | 810M | 2.7G | 11 | 25 | 42 | 5 | 125m |
ADL5321 | 2.3G | 4G | 14 | 25.7 | 41 | 3.3 | 37m |
ADL5320 | 400M | 2.7G | 13.2 | 25.7 | 42 | 3.3 | 47m |
HMC-ABH264-Die | 34G | 42G | 18.5 | 18 | 29 | 5 | 120m |
HMC633-Die | 5G | 17G | 29 | 23 | 30 | 5 | 180m |
HMC633LC4 | 5.5G | 17G | 30 | 23 | 30 | 5 | 180m |
HMC634-Die | 5G | 20G | 22 | 23 | 31 | 5 | 180m |
HMC634LC4 | 5G | 20G | 21 | 22 | 29 | 5 | 180m |
HMC635-Die | 18G | 40G | 19.5 | 23 | 29 | 5 | 280m |
HMC635LC4 | 18G | 40G | 18.5 | 22 | 27 | 5 | 280m |
HMC-ABH209-Die | 55G | 65G | 13 | 16 | 25 | 5 | 80m |
HMC-ABH241-Die | 50G | 66G | 24 | 17 | 25 | 5 | 220m |
HMC-APH196-Die | 17G | 30G | 20 | 22 | 31 | 5 | 400m |
HMC-APH403-Die | 37G | 45G | 21 | 23 | 32 | 5 | 475m |
HMC-APH510-Die | 37G | 40G | 20 | 26 | 35 | 5 | 640m |
HMC-APH596-Die | 16G | 33G | 17 | 24 | 33 | 5 | 400m |
HMC-APH633-Die | 71G | 76G | 13 | 20 |
| 4 | 240m |
HMC-APH634-Die | 81G | 86G | 12 | 19 |
| 4 | 240m |
HMC-AUH249-Die | 0 | 35G | 15 | 21 |
| 5 | 200m |
HMC-AUH256-Die | 17.5G | 41G | 21 | 20 | 27 | 5 | 295m |
HMC-AUH317-Die | 81G | 86G | 22 | 17.5 |
| 4 | 160m |
HMC-AUH318-Die | 71G | 76G | 24 | 17.5 |
| 4 | 130m |
HMC-AUH320-Die | 71G | 86G | 15 | 15 |
| 4 | 130m |
HMC594-Die | 2G | 4G | 10 | 21 | 36 | 6 | 100m |
HMC594LC3B | 2G | 4G | 10 | 21 | 36 | 6 | 100m |
HMC608 | 9.5G | 11.5G | 29 | 27 | 33 | 5 | 310m |
HMC609-Die | 2G | 4G | 20.5 | 21 | 36 | 6 | 170m |
HMC609LC4 | 2G | 4G | 20 | 21.5 | 36.5 | 6 | 170m |
HMC383-Die | 12G | 30G | 16 | 16.5 | 25 | 5 | 100m |
HMC383LC4 | 12G | 30G | 15 | 16 | 25 | 5 | 100m |
HMC451-Die | 5G | 20G | 20 | 20 | 30 | 5 | 127m |
HMC451LC3 | 5G | 20G | 19 | 19 | 29 | 5 | 114m |
HMC451LP3 | 5G | 18G | 18 | 19.5 | 28 | 5 | 120m |
HMC450 | 0.8G | 1G | 26 | 26 | 40 | 5 | 310m |
HMC465-Die | 0G | 20G | 17 | 22 | 30 | 8 | 160m |
HMC465LP5 | 0 | 20G | 15 | 23 | 28 | 8 | 160m |
HMC498-Die | 17G | 24G | 24 | 25 | 34 | 5 | 250m |
HMC498LC4 | 17G | 24G | 22 | 24.5 | 36 | 5 | 250m |
HMC499-Die | 21G | 32G | 16 | 24 | 33 | 5 | 200m |
HMC499LC4 | 21G | 32G | 17 | 23 | 34 | 5 | 200m |
HMC441-Die | 7G | 15G | 15.5 | 20 | 32 | 5 | 95m |
HMC441LC3B | 6G | 18G | 17 | 20 | 32 | 5 | 95m |
HMC441LH5 | 7G | 15.5G | 15 | 19 | 32 | 5 | 90m |
HMC441LM1 | 7G | 15.5G | 16 | 19 | 30 | 5 | 90m |
HMC441LP3 | 6.5G | 13.5G | 14 | 18 | 29 | 5 | 95m |
HMC442-Die | 17.5G | 25.5G | 15 | 21.5 | 28 | 5 | 84m |
HMC442LC3B | 17.5G | 25.5G | 13 | 22 | 26 | 5 | 84m |
HMC442LM1 | 17.5G | 24G | 14 | 21.5 | 27 | 5 | 85m |
HMC326 | 3G | 4.5G | 21 | 23.5 | 36 | 5 | 130m |
HMC406 | 5G | 5.9G | 18 | 27 | 38 | 5 | 300m |
HMC407 | 5G | 7G | 15 | 25 | 40 |
| 230m |
HMC415 | 4.9G | 5.9G | 20 | 23 | 32 | 3 | 285m |
